2027 Weaver 64' _{(19.51 m)}

Hull bottom

• 3 layers 9 mm okume plywood
• 1-layer 1700 E-glass impregnated with epoxy
• 1-layer 1208 Kevlar impregnated with epoxy
• Laminated douglas fir stringers encapsulated in fiberglass
• 1-layer 1708 E-glass inside bottom to chine
• 1-layer 1208 Kevlar inside bottom to chine

Hull sides

• 2 layers 6mm Okume plywood on hull sides
• 2 layers E-glass outside impregnated with epoxy
• Epoxy coat on okume from chine to sheer
• Laminated douglas fir battens, sheer clamp and chine
• Faired and painted bilges

Hull House

• 3 layers 9mm Okume plywood on house sides
• 2 layers 6mm Okume plywood on bridge floor
• 1-layer E-glass impregnated with epoxy
• ¼" tempered gray lite glass in #14-black for side, back and door windows.

Hull Finish

• A buildup of epoxy mixed with sand-able faring compound and sanded smooth
• Ablative/Copolymer anti-fouling bottom paint (3 coats), using "Interlux Interprotected epoxy primer system"
• Awlcraft engine room, lazarette, bilge and anchor locker for enhanced visibility and easier maintenance
• Single Awlcraft high gloss polyurethane boot stripe
• 6 coats of primer
• 3 coats of finish paint
• Paint Type - Awlcraft 3000 - standard topside color - snow white

General Interior

• Interior cabinetry and doors to be custom crafted, wood to be determined from builder's selection
• The Cabinetry is to be constructed with combination of plywood, Divinycell, tri-cell and Nida-core.
• Countertops to be Corian or Granite
• Brushed Nickel hardware is to be used throughout.
• Wood flooring where specified to be selected by owner from builders selection.
• Air conditioning - direct expansion, zoned with reverse cycle heat for complete climate control throughout the interior and with individual controls for staterooms and salon

Exterior Finishes

• Awlgrip 2000 paint
• Teak covering boards
• Teak toe rail with varnish finish
• Teak cockpit floor with black caulk
• 1" solid Stainless-steel rub rail

General Specs

• 1862 +/- gal fuel capacity
• 250-gal water capacity
• 52 gal holding tank with 24v macerator pump
• Marine Exhaust Linear Mufflers
• Recessed trim tabs
• Aluminum Fuel Tanks
• eastar electronic power steering
• Oval Exhaust tips
• 12" 24v DC bow thruster
• Lewmar Windless
• 16000 BTU Voyager with digital control for Fly bridge console and Mezzanine overhead

Decor

• All hardware metal finishes brushed nickel throughout
• Designer bedspreads for all beds
• Designer carpet, $40 per yard allowance
• Designer fabrics by Kravet with $45 per yard allowance
• Designer shams (2) per stateroom (3 for VIP forward layout)
• Next Day Blinds silhouette
• Interior finish satin, on vertical surfaces
• Throw pillows throughout including designer cords and fringes
• Ultraleather seating in salon and master stateroom and dinette
• Upgraded window panel fabric and trim

Main Salon and Galley

• Sliding composite door, painted on outside and veneer on inside, with electric door opener.
• Electrical panel
• 2-16,000 BTU AC-Voyager digital control. Air conditioning with reverse cycle heat that circulates from concealed registers behind the valances to maximize comfort while minimizing noise and drafts -individual temperature control
• 110-volt recessed lighting LED
• 24-volt accent rope lighting
• Ultra Leather sofas and dinette constructed by Costa Marine Canvas, Inc.
• Whisper Wall vinyl headliner, owner's choice of color, 1/8" foam and tricot backing
• Blinds for desired natural lighting and additional privacy
• •Carpeting, wall-to-wall with lined padding for sound absorption $40 per yard allowance
• Cocktail table, teak, high-gloss finish-hi/low
• Custom wood flooring at salon entrance
• Decorative throw pillows for sofa
• Fixed, side windows with tinted, tempered glass for style, natural lighting, and privacy
• 55" Smart TV on a raise and lower mechanism
• Lambrequins, fabric upholstered-inlaid in teak frames
• Lighting, overhead LED lights recessed in headliner with dimmer switches and direct decorative rope lighting behind valances, 24 VDC
• L-shaped lounge with lift cushions for storage
• Main electrical panel with AC selector breakers
• Teak cabinetry with drawers and bottle storage, finished veneer interior
• Valances solid teak, fluted with solid teak blind covers
• Custom wood flooring in Galley
• Custom galley island, 360-degree access with refrigeration and freezers, Corian or Granite countertop
• Dinette couch with removable cushions and storage underneath
• Dinette table, teak, high-gloss finish with oversized teak pedestal, thru-bolted
• Electric range, 4-burner cook top, surface-mounted
• Exhaust fan, high velocity designed for exterior ventilation
• Garbage disposal in sink
• Ice maker, clear ice type concealed in companionway
• Lighting, overhead LED lights recessed in headliner with dimmer switches
• GE Microwave/convection oven located in upper galley cabinet
• Pantry, port side aft of companionway stairs
• Sink, double-bowl stainless steel, under-mounted in countertop with brushed nickel galley faucet
• Stools - (3) swivel type bar stools on aft side of galley island
• Storage cabinets in upper galley, varnished teak doors with finished maple interior
• Storage cabinets and drawers in lower galley, varnished teak doors and faces with stowage for utensils, and other items
• Storage above dinette
• Water tank level gauge in pantry
• Corian or Granite countertops and sink with Grohe single lever faucet
• Appliances:1.    Ice Maker -Whirlpool
• 2.    Refrigerator-1 Subzero drawer systems (2 drawers)
• 3.    Freezer-2 Subzero drawer systems (4 drawers)
• 4.    4-burner cook top with exhaust fan
• 5.    Microwave/Convection -GE
• 6.    Garbage disposal

Master Stateroom

• Queen style bed with drawers and storage under bed, (2) large drawers, for forward and aft bank
• Soft goods by Costa Marine Canvas, Inc. including bedspread and pillows. Designer fabrics by Kravet with $45 per yard allowance
• 12000 BTU Voyager - Digital control air conditioning with reverse cycle heat that circulates from concealed registers behind the valances to maximize comfort while minimizing noise and drafts - individual temperature control
• Cedar lined hanging closets
• 110v recessed lighting or LED in headliner with dimmer switches
• 24v accent rope lighting
• •Private access to master head
• Carpet on floors with a $40 per yard allowance
• Decorative LED indirect rope lighting from underneath bed platform
• End tables each side of bed
• Headboard, upholstered
• Whisper Wall headliner, owners color selection, 1/8" foam and tricot backing
• Mattress, Handcraft, Innerspring System
• Pillow shams (2), with throw pillows
• Reading lights, overhead with separate switches
• 36" Smart

Master Head

• Fresh Water Flush Raritan Atlantes Head
• Custom fiberglass shower with Grohe faucet and Rule 800 sump pump
• Fresh water flush Raritan head
• Wallpapered walls
• Air conditioning/heat with register
• Custom wood flooring
• Exhaust fan with vent in soffit
• Lighting, overhead LED lights recessed in soffit and in ceiling
• Linen Storage with shelves and mirrored door in master head
• Lower vanity with curved teak face
• Master Stateroom head countertop, CORIAN
• Master Stateroom head, one-piece custom frameless shower doors
• Medicine cabinet with mirrored doors
• Receptacle, 120V - GFCI
• Shower light
• Towel bar and ring - brushed nickel

VIP Stateroom

VIP Head

• Freshwater Flush Raritan head
• Wallpapered walls
• Access from guest quarters
• Air conditioning/heat
• Custom wood flooring
• Exhaust fan with vent in soffit
• Corian or Granite countertop with rounded edges and sink with brushed nickel faucet
• Lighting, overhead LED lights recessed in soffit and in ceiling
• Lower vanity with curved teak face
• Medicine cabinet with mirrored doors
• Receptacle, 120V - GFCI
• Shower light
• Stall shower, fiberglass with brushed nickel shower fixtures and with drain to automatic sump pump in bilge
• Towel bar and ring - brushed nickel

Crew Quarters

• Soft goods by Costa Marine Canvas, Inc. including bedspread and pillows. Designer fabrics by Kravet with $45 per yard allowance
• 19" Samsung smart TV
• 24v accent lighting
• Carpeted floors with a $40 per yard allowance
• (2) bunk lights
• 9000 BTU Voyager with digital control air conditioning with reverse cycle heat that circulates from concealed registers behind the valances to maximize comfort while minimizing noise and drafts - individual temperature control
• Decorative indirect rope lighting from underneath bed platform and behind valances
• Hanging locker, teak, cedar-lined with bar for hanging clothes
• Lighting, overhead LED lights
• Whisper Wall headliner, owner's choice color, 1/8" foam and tricot backing
• Storage drawers located under hanging locker
• Upper/lower bunks with mattress and lift up bottom for storage

Guest Quarters

• (2) bunk beds with mattress and lift up bottom for storage in both staterooms
• 32" Smart TV
• Soft goods by Costa Marine Canvas, Inc. including bedspread, 2 shams and pillows. Designer fabrics by Kravet with $45 per yard allowance
• Carpeted floors with a $40 per yard allowance
• (2) bunk lights
• 9000 BTU Voyager with digital control air conditioning with reverse cycle heat that circulates from concealed registers behind the valances to maximize comfort while minimizing noise and drafts - individual temperature control
• Decorative indirect rope lighting from underneath bed platform and behind valances
• Hanging locker, teak, cedar-lined with bar for hanging clothes
• Lighting, overhead LED lights
• Whisper Wall headliner, owner's choice color, 1/8" foam and tricot backing

Guest Head/ Crew Head

Companion Way

• Whisper Wall headliner, owner's choice color, 1/8" foam and tricot backing
• Awlgrip bilge areas with access hatches, snow white and lighted for easier maintenance and cleaning
• Carpeting, carpeted steps from galley through companionway $40 per yard allowance
• Central vacuum unit connection with accessories
• Laundry center with stackable, front-loading washer and dryer behind teak door
• Lighting, overhead LED lights recessed in headliner

FlyBridge

• Electrical panel for electronics (16 breakers)
• Hom
• Running lights
• Fuel Transfer switch with flow indicator lights
• High Water Alarms
• Bilge pump lights
• Genset indicator light
• 110-volt electrical outlet
• Fresh water wash down under seat
• Back-up engine controls supplied by engine manufacturer
• Custom helm pod with single lever electronic controls with built in bow thruster controls
• Engine shutdown switches at cabinet in console
• Extended overhang for extra room to move behind helm and companion seats with anodized aluminum aft railing
• Fire system control with automatic and manual discharge and override system located at console
• Fresh water outlet forward locker
• Freezer, top-loading, for bait and food storage, forward
• Gauges/electronic displays, include hour meter reading for main engines supplied by manufacturer
• Helm and companion seats, 2 seats, teak, ladder back with 4" stainless pedestals and removable cushions and covers by Release Marine
• Instrumentation based on standard engine package, lighted with switches in radio box
• Lighted Ritchie compass, large and flush-mounted on centerline
• Lounge seating to port and starboard and at forward end of helm console with vinyl covered foam cushions, hinged for access to storage under seats
• Non-skid deck for traction and durability
• Recessed electronics box in console for custom electronics package that is easily viewable and protected from the elements by Teak fitted lid with gasket and stainless-steel gas pistons
• Recessed radio boxes, large radio boxes on port and starboard sides of console with switch panel inside
• Removable fly bridge bench seat backrest forward facing at aft ends of port bench seats
• Trim tab control switch mounted at console
• (2) Trumpet style air horns
• Under helm access with lights

Running Gear

• Flush-mount stainless steel struts
• (2) Aquamet 22, 3½" shafts
• 5 blade Nibral propellers Michigan
• (2) 2 ¾" Stainless steel rudders
• Dripless rudder ports and glands by Tides Marine
• Shaft tube with dripless shaft seals by Tides Marine
• Custom raw water sea chest-grate

Forward Deck

• Large Anchor locker with drain
• Fresh water-wash down in anchor locker
• Fortress Anchor with 30' chain and 300ft of¾ nylon rope
• Non-skid walk area
• (4) cleats
• (1) Bowmar hatch with shade and screen

Cockpit

• Saltwater wash down pump
• Stainless steel bait freezer
• Stainless steel lined travel freezer
• Tackle drawers with stainless steel drawer guides
• Engine room entrance
• Transom tuna door with stainless steel hinge
• eak covering boards
• (6) rod holders in covering boards
• Eskimo crushed ice machine with ice storage
• (2) recessed stereo speakers in overhang
• (3) recessed air condition vents with 16000 BTU AC
• Stainless steel hawser pipes in transom corners
• (2) 15" cleats
• Lazarette access
• (2) under water single color lights
• Release Marine Fighting Chair (and below items) Teak seat upgrade 23 x 23 with 36" footrest
•  (1) 6- hole chair launcher, teak, (4) 15Q no bolt rod holders
•  Bait tray teak- includes non-skid
•  Back pad teak- 12Q curved
•  Tackle drawer teak face with starboard drawer
• Fighting chair cover
• Aluminum backing plate, laminated in cockpit sole, for fighting chair or table
• Dockside electric connection - (2) 50 amp/220V
• Dockside water connection with pressure reducing valve in cabinet under gunwale
• Engine room access with steps to engine room
• Extended flybridge overhang for shade
• Fresh and salt water wash down with hose bib located in cabinet under gunwale
• Indirect rope lighting underneath the coaming (LED)
• Ladder to flybridge, one-piece, anodized aluminum
• Lazarette hatch with access to steering system, trim tabs, drain pumps
• Lighting, recessed LED deck lights in flybridge overhang
• Observation mezzanine with starboard aft facing lounge seating with Sunbrella covered cushions, hinged seats, tackle cabinet
• Stainless steel oversized refrigerated chill box in mezzanine step for direct access from cockpit
• Self-bailing cockpit with large scuppers
• Stainless steel gas springs on all hatches and lids
• Straps with padding to secure transom door and gate while open

Engine Room and Mechanical

• (1) 9,000 Sea Keeper Gyro
• (1) 21.5 KW Onan Genset with Sound shield
• (2) MTU 12V 2000HP M96x with ZF3050A Gear 2.03 Ratio
• 1200GPD Sea Recovery Water Maker
• Livos mist eliminators
• Aluminum stringer caps
• (4) 24V exhaust fans
• (2) 230V Grundfos multi stage speed fresh water system with on deck fresh water fill and cockpit dockside supply inlet with pressure reducing valve
• 30-gal stainless steel Indel Webasto hot water heater
• 110 volts and 24-volt engine room lighting
• Eskimo ice machine- 600 lb. per day
• Battery chargers (1) 240-volt 60 amp & (1) 24volt 10 amp for bow thruster
• Racor filters -single on engines -single on generators
• Batteries -(8) Deka group 27
• Battery switches-Blue Sea Systems 660-amp rotary switches
• Voyager compressor for drink box and cockpit freezer
• Voyager compressor for travel freezer
• (4) bilge pumps-3 with high water alarms
• Sea strainer on Gensets
• 24-volt salt water-wash down pump with strainer
• Fuel sight gauges
• Water and holding tank gauges
• External sea strainers for main engine pick-ups
• Fire suppression system, automatically and manually operated and tied into main engine and generator ignition and ventilation systems with override
• Fresh water filter - paper
• Fresh water supply in engine room for general maintenance and cleaning
• Fuel transfer, 24 VDC pump Oberdorfer
• Hour meters on generators
• Internal sea strainers for generator, and all other sea water pickups
• Engines- Marine Exhaust Linear Mufflers with surge tubes in engine room
• Generator- Lift muffler
• Oil changing system, gear type pump for main engines, transmissions, and generator
• PEX plumbing, fresh water system with manifold system to isolate individual areas
• Propellers, Class "S" pitch tolerance (ISO 484/2) and dynamic balancing. Advanced design cambered blade sections for optimum performance. Interceptors strips to adjust engine load. Nibral alloy for maximum durability.
• Stainless steel rudders, rudder bearing with dripless seal laminated into hull
• Seacocks, bronze, ball-type sea valves for all thru- hulls below the water line - Awlgrip snow white
• Shafts - (2) 3 ½" Aquamet high-strength stainless steel, double-taper with machined keyway and main engine couplings
• Struts - thru-water, stainless steel, with cutlass bearings
• Tides Marine water lubricated dripless shaft seals with crossover water supply from both engines
• Trim tabs, port and starboard tabs recessed in transom, individual controls for each tab with fiberglass covers

Plumbing

• Hot & cold-water supply
• Indel Webasto 30-gal stainless steel hot water heater
• (2) 230-volt Grundfos water pumps
• 250 gal built in fresh water tank
• 2-gal Aluminum holding tank
• Rule 2000 pumps for showers with 15-gal tank and float switch

Electrical

• Wired to ABYC standards All Wires to be labeled at each end
• (1) 50 amps 125/250 volt- AC shore power cords
• (1) 50 amps 125/250 volt- AC shore power inlet at port forward cockpit
• Paneltronics Panels
• Dyna plate bonding system
• Transom mounted zinc
• All necessary wiring to supply all specified 110 volts and 220-volt systems
• Voyager, Eskimo Ice, water maker, dryer and water heater systems to be 220 volts
• 24V DC ship's service throughout
• 240/120V AC power supply
• 110V outlet in engine room on aft bulkhead
• Anchor light/navigation lights
• Battery chargers, (2) with thermal cutoff and switching system for complete integration
• Battery distribution panels with battery cutoff for ship service batteries and engine batteries
• Bonded electrical system with ground plate
• Dimmers, DC LED interior lighting throughout excluding companionway
• Engine room lights, recessed AC and DC with switch at engine room entrance
• Lighting, overhead LED lights recessed in ceiling and rope style decor lights concealed by teak valances

Half Tower

Half Tower with Molded Top 64' Sportfish, Polish Pipe

• (2) Antenna, stands-offs, no Halyards, 3-sided track on perimeter rail.
• (6) Hardtop lights to be Tri-color Lumitec Lights with fiberglass recess (blue, white & red)
• (1) Radar Pod: Large oval style, mold #973, w/Sliding door for teaser reels
• (1) Molded 2 in 1 24V LED light pod with S/S Bezel
• (1) Molded 24V-LED Light Fwd platform S/S Bezel
• (1) Recessed electronics box with lid
• (1) Bridge ladder no handrails, teak steps
• (2) Handrails full length salon window
• (1) Molded satellite TV mount
• (1) Bridge rail, leg to leg, double aft to outer main leg
• (8) Rod holder polished weld to rail PBT style
• (6) Rod holder polished aft legs 3-P-3-S PBT style
• (1) 42' outrigger Rupp Bigg Riggs, HD 4 spreader, bridge release large solid aft bar
• (1) Flag staff aft
• (1) Nav. Lights port, stbd, stem molded
• (1) Upgraded tower FWD X brace, side diagonals, and hardtop brace to contour style

Electronics

All electronics are to be supplied by the owner.

Mechanical Disclaimer

Engine and generator hours are as of the date of the original listing and are a representation of what the listing broker is told by the owner and/or actual reading of the engine hour meters. The broker cannot guarantee the true hours. It is the responsibility of the purchaser and/or his agent to verify engine hours, warranties implied or otherwise and major overhauls as well as all other representations noted on the listing brochure.

Disclaimer

The company offers the details of this vessel in good faith but cannot guarantee or warrant the accuracy of this information nor warrant the condition of the vessel. A buyer should instruct his agents, or his surveyors, to investigate such details as the buyer desires validated. This vessel is offered subject to prior sale, price change or withdrawal without notice.

Listing MLS by Yachtr.com
